GB
IE
14 SND 3600 A2
Operating components (see fold-out pages)
LED PWR
2 SCAN button
3 Insert slot for the negative or slide magazine
4 USB connection cable
5
Film holder
6 Slide magazine
7 Cleaning brush
Handling and operation
In this chapter you receive important information for the handling
and operation of the device.
Insert the negative strip
♦ Release the fastener on the front of the fi lm holder
5
and open
the holder.
♦ Insert the fi lm strip, correctly orientated, into the holder. Ensure
that holes of the negative strip are placed on the corresponding
retaining tabs on the holder, so that the negative strip can not
move.
♦ Close the holder making sure that the cover locks into place.
Inserting slides
♦ Place the slides, with the sides the right way round, into the
intended slot of the slide magazine
6 .
♦ First guide the slide magazine 6 , with the viewing window
leading, into the insert slot 3 .
By means of the slider, located laterally on the slide magazine 6 , the
slides contained in the slots are pushed individually into the scanner.
