- 11 -
1. For this, first fold the projector t out.
2. Switch the function on with the PROJEC-
TION button a.
3. Direct the projector t onto the desired
surface area. Before you can turn the pro-
jector t - if so desired - to the side, you
must carefully pull its base up from the
device housing.
4. Using the focus regulator 1( sharpen the
image.
5. The time will now be projected onto the
desired surface area for the pre-adjusted
timespan (see section "Adjusting the Pro-
jection duration").
6. To display the projection back to front,
press and hold the button PROJECTION a
for one second. Pressing and holding it
once again lets the projection appear as
normal.
7. Should you wish to switch this function off
prematurely, press the PROJECTION but-
ton a and fold the Projector t in.
Button lock
Press and hold the MODE/LOCK button e
until the key symbol is indicated in the dis-
play g. The normal key functions are now
blocked. The buttons retain, however, the
function “Alarm stop”. In addition, the button
SNOOZE/DIMMER y as the snooze button
and for setting the display brightness. To dis-
able the button lock function, press and hold
the MODE/LOCK button e once again until
the key symbol extinguishes.
Cleaning
Warning!
Always remove the mains power plug
before cleaning the appliance! Moisture
penetrating into the appliance creates
the risk of electric shock! Additionally,
the appliance could become irreparably
damaged!
Clean the housing of the radio alarm only
with a slightly moist cloth and a mild deter-
gent. Ensure that moisture cannot permeate
into the appliance during cleaning!
Troubleshooting
The appliance doesn't work.
> Is the plug of the power cable 2! inserted
firmly into the power socket?
> Has the circuit breaker tripped?
> Is there a power cut?
Poor VHF reception.
> Change the alignment of the wire aerial
2)
. If necessary, firmly position it with
adhesive tape.
Poor MW reception.
> Change the alignment of the appliance.
Loss of all programming after a power
cut.
> Batteries were not inserted to retain the
memory.
> The batteries inserted for memory reten-
tion are exhausted. Replace them.
The projected time is difficult to read.
> Using the focus regulator 1( sharpen the
image.
Notice regarding conformity
This appliance has been tested against, and
found to be in compliance with, the funda-
mental requirements and other relevant stipu-
lations of the EMC Directive 2004/108/EC,
as well as the Guidelines of the Low Voltage
Directive 2006/95/EC.
Importer
KOMPERNASS GMBH
BURGSTRASSE 21
44867 BOCHUM, GERMANY
www.kompernass.com
