Setting up and connecting
SLS 2000 B2
GB
Device description
Operating LEDs charging station
2 Connection socket for power supply unit
3 Retaining device iPad/Tablets
4 USB port
5 USB port
6
Connection socket for the adapter cable
7
Connection socket for the adapter cable
8 Connection socket for the adapter cable
9
Mains power supply unit
10
Mains power supply unit operation LED
11
Adapter cable Nokia large (MC01)
12
Adapter cable Nokia small (MC28)
13
Adapter cable Sony Ericsson (MC11)
14
Adapter cable Playstation Portable (MC20)
15
Adapter cable Motorola (MC07)
16
Adapter cable Siemens (MC02)
17
Adapter cable Nintendo DS Lite (MC22)
18
Adapter cable Samsung (MC25)
19
Adapter cable Mini USB (MC17)
20
Adapter cable Micro USB (MC19)
21
Adapter cable LG (MC12)
22
iPod/iPhone/iPad cable
Electrical connection
IMPORTANT
► Before connection of the device compare the specifi cations for the required
input voltage on the rating plate with the intended voltage source for opera-
tion. This data must be compatible to avoid possible damage to the device.
► Make sure that the mains power supply unit's 9 cable is not damaged
and does not run across hot surfaces and/or sharp edges, otherwise it will
become damaged.
► Make sure that the mains power supply unit's 9 cable is not stretched or
knoted.
♦ Plug the mains power supply unit 9 into a mains wall socket. The operation
LED
10
lights up.
♦ Connect the mains power supply unit 9 to the charging station by inserting
the plug into the connection socket 2 on the rear panel of the device. The
operating LEDs glow.
