Silvercrest SMJB 1.5 A1 - Handbuch (Seite 14)

11 SMJB 1.5 A1
GB
IE
Playback from USB memory devices/ SD/
MMC memory cards
This appliance is equipped with a USB port and an SD-/MMC card slot. You
can use these interfaces to play MP3 and WMA data. USB storage devices
and SD-/MMC- memory cards with a size of up to 16 GB are recognised.
♦ Flip up the operating element fl ap 18 .
♦ Connect the USB storage device to the USB port 4 resp. insert a memory
card with the label facing up into the card slot 7 .
♦ Turn the VOLUME regulator 17 clockwise to switch the appliance on and to
adjust the sound volume.
♦ Place the switch CD/AM/FM at "CD".
♦ Press and hold the button CD/USB/SD 16 until the indicator resp.
appears in the display 8 .
The appliance now reads the respective medium. Subsequently, in the display 8
appears the number of extant fi les (for example ) and the number of titles they
contain. Playback will start automatically and in the display 8 the title and the
fi le number are displayed alternately. In addition, indicated is
PLAY and the
fi le format (MP3 or WMA) in the display 8 . The USB indicator lamp 5 resp.
the SD / MMC indicator lamp 6 glow.
NOTICE
► A skipping or direct selection of fi les is not possible. Playback always starts
with the fi rst track on the media.
♦ Further operation is identical to the playback of CDs (see also chapter
Basic Operation (with CD/MP3 playback)
).
♦ Before you disconnect the USB storage device from the USB slot 4 resp.
the SD or MMC card from the card slot 7 , stop playback by pressing the
button STOP 15 .
NOTICE
► Because of the many diff erent formats, specifi cations and manufacturers of
fl ash memory mediums we can not guarantee that every memory medium
can be played. It is not possible to playback hard discs connected to the
USB port
4 .
