Safety instructions
Before each use check that the trolley is in a faultless condition. If damage is ■
detected, the trolley may no longer be used.
Never load the trolley with a weight exceeding 150 kg. ■
Only use the trolley on smooth and even surfaces, not on steps or steep inclines. ■
Always secure the load area against unintentional pulling out or sliding ■
together with the safety clip, as illustrated on the fold-out page.
Before use, always pull the bow-shaped handle out so that it engages in the ■
fi nal position. If you do not, it could slide back together when under load.
After assembly, and at regular intervals thereafter, check each individual ■
screw connection for its fi rmness.
Should it be necessary to dismantle one or more screw connections, new ■
lock nuts are to be used for the reassembly.
Assembly
Attach the four castors as shown in the illustration on the fold-out side.
After assembly, check each individual screw connection for its fi rmness.
Grip element
The grip element consists of two square tubes and the handle held by them.
The profi le frame between the square tubes locks and unlocks the grip element.
In order to adjust the handle for height resp. to bring the handle element into the
upright position, the profi le frame must be pushed down. Two return springs bring
the profi le frame back into rest position. The grip element and the handle engage
audibly into the upright position resp. into the extended condition.
