5 GB/IE
Introduction / Safety advice
29 Washer (fastening bolt vice rear jaw)
30 Fastening bolt (vice rear jaw)
31 Hexagonal socket head screw (fastening of
mounting piece)
32 Base plate
33 Saddle
34 Washer (hexagonal socket head screw saddle)
35 Hexagonal socket head screw (fastening of
saddle)
36 Mount
37 Clip
38 Rear mounting piece
39 Nut (mounting bolt guard mount)
40 Mounting bolt (guard mount)
41 Vice
 Included items
Check that all the items and accessories are pre-
sent and that the product and its all parts have no
defects immediately after unpacking. Do not as-
semble the product if any of the included items list-
ed below are missing.
1 x Base plate
1 x Saddle
2 x Washers (hexagonal socket head screw saddle)
2 x Hexagonal socket head screws (fastening of
saddle)
2 x Hexagonal socket head screws (fastening of
mounting pieces)
1 x Mount
1 x Adjustment screw with rubber buffer (long)
2 x Mounting bolts M10 (angle grinder)
2 x Mounting bolts M8 (angle grinder)
2 x Mounting bolts M6 (angle grinder)
2 x Nuts (mounting bolts M10 angle grinder)
2 x Nuts (mounting bolts M8 angle grinder)
2 x Nuts (mounting bolts M6 angle grinder)
1 x Handle
1 x Metal rod
1 x Safety guard
1 x Adjustment screw with rubber buffer (short)
2 x Mounting pieces
2 x Plastic location pieces (mounting pieces)
2 x Fastening screws (vice)
1 x Vice adjustment thread (vice)
1 x Rotary adjustment knob (vice)
1 x Guide bolt (vice)
1 x Guide (vice)
1 x Clip
3 x Square nuts (guide rail)
1 x Stop (vice)
1 x Stop (vice rear jaw)
2 x Fastening bolts (vice rear jaw)
2 x Washers (fastening bolts vice rear jaw)
1 x Mounting bolt (guard mount)
1 x Nut (mounting bolt guard mount)
1 x Nut (guard mount)
3 x Distance pieces (60 / 90 / 130 mm)
3 x Washers (mounting bolt)
2 x Plastic bushings M6
2 x Plastic bushings M8
 Technical data
Max. dimensions of the workpiece:
Tubes:
round tube: 30 x 2 mm (ø x t)
other shapes: 30 x 2 mm (W x t)
Bars: round bar: ø 12 mm
other shapes: 12 mm (W)
Plates: 45 x 2 mm (W x t)
Material / Weight:
Material:
Aluminium alloy, cast iron (main material)
Weight: 2.
I kg (±5%)
Safety advice
WARNING! Read all the safety advice
and instructions. Failure to observe the safety
advice and instructions could result in electric shock,
fire and/or serious injury.
General safety advice

DANGER OF LOSS OF LIFE
AND ACCIDENT TO INFANTS
AND CHILDREN! Never leave
children unsupervised with the packaging materials.
