4 GB/IE
Congratulations!
With your purchase you have decided on a
high-quality product. Get to know the product
before you start to use it. Carefully read the
following operating instructions. Use the product
only as described and only for the given areas
of application. Keep these instructions safe.
When passing the product on to a third party,
always make sure that the documentation is
included.
use only for designated use
This item is a wall rack intended for private use
for a maximum of two bicycles with crossbars.
It is not suitable for tricycles or bicycles with
support rollers.
technical details
Dimensions (once constructed):
approx. 33.5 x 43 x 65cm (W x H x D)
Max. load: 50kg
Manufacturing date: 2013
Scope of delivery,
part designations (fig. a)
1 x bicycle wall bracket (A)
6 x screw (B)
6 x dowel (C)
2 x hook (D)
1 x frame hook (E)
1 x instructions for use
Safety advice
danger of injury!
• Do not attempt to carry out maintenance or
repair work on bicycles when they are
attached to the wall-mounting.
• Ensure the wall provides sufficient support for
the bicycle wall bracket.
• When drilling, always watch out for supply
lines inside the wall.
• When hanging the bicycles, make sure that
they rest securely on the notches and that they
are hanging from the hook.
• Only use the included mounting materials on
solid concrete walls.
• Use appropriate mounting materials on light
construction walls.
• Maximum load of 50kg only applicable
when wall bracket has been mounted as per
instructions.
• Do not exceed maximum load of 50kg.
• Check all parts of the bicycle wall bracket
regularly. Tighten any loose screws and
replace any damaged parts.
• No liability is assumed for personal injury
due to improper use.
• The maximum capacity load of 50kg can
only be reached, if two men’s bicycles are
hung over both of the brackets of the wall
rack at the same time, or if one men’s bicycle
is hung over both brackets and one ladies’
bicycle is hung on the frame hook.
• Do not stand or walk under the hanging
bicycle.
assembly instructions
note:
•
Before beginning assembly please
check that there is sufficient space at
the assembly location. you must take
the width and height of your bicycles
into account.
•
2 people recommended for
assembly.
Remove the cable ties on frame (6) and fit the
frame into the notches (7) (fig. B).
You will need the following tools (not included)
to mount the wall bracket:
• 1 x Drill
• 1 x 8mm – drill
• 1 x Crosshead screwdriver
Hold wall bracket up to wall in a suitable loca-
tion and mark 6 mounting holes with a pencil.
Drill mounting holes as marked and insert wall
plugs into holes to be flush with surface.
Attach wall bracket to wall using the 6 screws.
ensure frame is firmly in position (fig. c).
