Overview
 Lever arm
 Hand grip
 Roller base
 Rotatable loading surface
 Swivelling head
Technical data
Loading per roller base: 150 kg
Loading Lever arm: 150 kg
Weight: approx. 1,1 kg
Placing furniture on the roller
bases
1. Ensure that there is sufficient space available to
work safely.
2. Remove obstacles, e.g. other furniture items,
within ca. 1,5 m from the roller bases
.
Hints:
To avoid uneven lifting, always take into account
the load centre of gravity and place the lever
arm
 on the side to be lifted.
1. Hold the lever arm
 at the hand grip . With
this you will require the least effort.
2. Push the swivelling head
 of the lever arm
under the furniture and in the middle of it (A).
3. To lift the furniture, slowly press the lever arm

down (B).
4. Hold the lever arm
 pressed down.
5. Place one roller base
 (C) under each raised
corner of the furniture piece.
6. To lower the furniture piece onto the roller base
, slowly lift the lever arm  (D).
7. Remove the lever arm
.
8. Repeat the above procedure for the opposite
side of the furniture piece.
D
C
C
B
A
