POWERFIX PDM 250 A2
6 - English
AC voltage
Range Resolution Precision
2V 1mV
± (1.0%+5) 20V 10mV
200V 0.1V
250V 1V ± (1.2%+5)
Input impedance: 10MΩ
Frequency range: 40Hz to 400Hz
Overload protection: 250V AC RMS
Display: average value (RMS of the sine wave)
DC current
Range Resolution Precision
200μA 0.1μA
± (1.0%+5)
2mA 1μA
20mA 10μA
± (1.2%+5)
200mA 0.1mA
10A 10mA ± (2.0%+5)
Overload protection: F1: F 250mA / 250V fuse
F2: F 10A / 250V fuse
Maximum input current: 10A (input current > 2A for continuous measurement < 15 seconds and
interval > 15 minutes)
AC current
Range Resolution Precision
2mA 1μA ± (1.2%+5)
20mA 10μA
± (1.5%+5)
200mA 0.1mA
10A 10mA ± (3.0%+7)
Overload protection: F1: F 250mA / 250V fuse
F2: F 10A / 250V fuse
Maximum input current: 10A (input current > 2A for continuous measurement < 15 seconds and
interval > 15 minutes)
Frequency range: 40Hz to 400Hz
Display: average value (RMS of the sine wave)
