Multi-Contact MA034 Benutzerhandbuch
Multi-Contact Relais
Advanced Contact Technology
www.multi-contact.com
1 / 4
FSA20A-K/...
FSA20A-L/...
1)
Suitable as set (blade and cylinder pin)
FSA20A-KL-SET Order No. 12.0890
MA034 (de_en)
Montageanleitung
MA034 (de_en)
Assembly instructions
Klingenwechsel am Kontaktbolzen der Flach-
schienenbgriffe FSA20A-K/... FSA20A-L/...
Changing the blade on the contact bolt of the
fl at contact clamps FSA20A-K/... FSA20A-L/...
Inhalt
Sicherheitshinweise....................................................................2
Notwendiges Werkzeug ............................................................3
Demontage ................................................................................3
Montage ....................................................................................3
Content
Safety Instructions ......................................................................2
Tools required ............................................................................3
Dismantle ..................................................................................3
Assembly ...................................................................................3
Klinge
1)
Blade
1)
Ø 2.5x14
Zylinderstift
1)
Cylinder pin
1)
Kontaktbolzen
Contact bolt
1)
zu bestellen als Set (Klinge und Zylinderstift)
FSA20A-KL-SET Bestell-Nr. 12.0890
