Marc One 5
External Power Supply
AC/DC switching adapter Mean Well GE18/12-SC
DC plug (+) pin 2.1mm; (-) outside ring 5.5mm
Input 100 - 240 V AC; 50 - 60 Hz; 0.7 A
Output 12 V DC; 1.5 A
Dimensions & Weight
W x H x D (width x height incl. feet x depth)
210 x 49,6 x 220 mm /
8,23 x 1,95 x 8,66 inch
Unit weight 1,45 kg / 3,2 lb
Shipping weight (incl. packaging) 2 kg / 4,4 lb
Internal Power Supply
Operating voltage for analog audio +/- 17 V
Operating voltage for headphone amplifier +/- 19 V
Operating voltage for relays +12 V
Operating voltage for digital audio +3.3 V, +5 V
Headphones Output; 6.35 mm (1/4") TRS Jack
Wiring
Tip = Left, Ring = Right,
Sleeve = GND
Source impedance 20 Ω
Frequency range (-3 dB) 10 Hz - 200 kHz
Noise (A-weighted, 600 Ω) -97 dBu
THD + N (0 dBu, 10 Hz – 22 kHz, 600 Ω) 0,002 %
THD + N (0 dBu, 10 Hz – 22 kHz, 32 Ω) 0,013 %
Max output power (600 Ω) 2 x 190 mW
Max output power (250 Ω) 2 x 330 mW
Max output power (47 Ω) 2 x 400 mW
Fade-out attenuation (600 Ω) -99 dB
Crosstalk (1 kHz, 600 Ω) -75 dB
Dynamic range 117 dB
Reference: 0 dBu = 0,775V. All specifications are subject to change without notice.
