Compatibility
The skulpter 500 is a module to be installed into an API 500 se-
ries compatible rack frame (not included). It needs the power
supply and the audio connectors provided by this frame and
does not function stand alone.
The current consumption is 115 milliamperes at +/- 16 volts
DC. The skulpter 500 meets all mechanical and electronic
specifications of the VPR Alliance, providing the highest level
of compatibility with common 500 series rack frames.
Installation
Just follow these easy steps to install your skulpter 500:
1. Switch your API 500 series compatible rack off and discon-
nect the power cable from mains.
2. Insert the module into a free slot of your rack. Make sure the
PCB connector matches with the rack connector.
3. Gently push the module in place - do not use any extensive
force here!
4. Tighten the front panel with two screws provided by your
rack manufacturer.
5. Connect your audio cables (see page 6 for more info) and
apply power to your rack.
And this is already it. Have lots of fun with your skulpter 500!
