5
1. RFS 2.2 TRANSCEIVER AS TRANSMITTER
The RFS 2.2 transceiver operates as a remote control or radio flash trigger for
one or more broncolor power packs or monolights equipped with an RFS 2
interface. Power packs or monolights not equipped with an RFS 2 interface
can be operated by connecting an RFS 2.2 Transceiver (as receiver) – see
Chapter 10.
All devices, whether with a built-in RFS 2 or an external RFS 2.2 receiver are
compatible. If several RFS 2 units are to communicate with each other, they
must be set to the same studio address. RFS 2 units with the same studio ad-
dress can be remote-controlled simultaneously. By using different studio ad-
dresses, several groups of devices can be reliably operated independently of
each other. Flash synchronisation takes place either via the hot shoe, or using
the camera’s sync contact. The operating distance is up to 50 m in the open
air, or up to 30 m in a building. The transmitter is fitted with two AA batteries.
Attention! Although this radio system allows up to 99 studio addresses,
the number of channels that is effectively available is restricted by the
RFS 2 flash unit to be controlled.
For further instructions, please see the operating instructions for the flash
unit concerned.
