Luminox 8000 Series - Handbuch (Seite 3)

30
10 20
12
3 9
6
10 1
2
3 7
8
9
15
60
30
45
2 1
III
30
10 20
12
3 9
6
10 1
2
3 7
8
9
15
60
30
45
I II III
2 1
Push-button B
Push-button A
Adjusting the chronograph
hands to zero position
Example:
One or several chronograph hands are not
in their correct zero positions and have to be
adjusted (e.g. following a battery change).
Pull out the crown to position III
(all 4 chronograph hands are in their
correct or incorrect zero position).
Keep push-buttons A and B depressed
simultaneously for at least 2 seconds
(the centre stop-second rotates by
360° corrective mode is activated).
Centre stop-second
1 ⁄ 10 second counter
Minute counter
Hour counter
Adjusting the centre stop second
Single step A 1 x short
Continuous A long
Adjusting the next hand B
Adjusting the 1 ⁄ 10 second counter hand (position 6h )
Single step A 1 x short
Continuous A long
Adjusting the next hand B
Adjusting the minute counter hand
and the hour counter hand
(mechanical coupled)
Single step A 1 x short
Continuous A long
A
B
A
III I II
Returning the crown to position I
Termination of the chronograph hands
adjustment (can be carried out at any time).
B
A
