Seite 33
25
Vorbereitung
Anschlüsse
Wiedergabe
Einstellungen
Tipps
Anhang
DEUTSCH
• RMS-Leistungsausgabe:
(20 Hz – 20 kHz, gleichzeitige Ansteuerung
beider Kanäle)
90 W × 2 (8 Ω/Ohm)
140 W × 2 (4 Ω/Ohm)
• Gesamtklirrfaktor:
(20 Hz – 20 kHz, gleichzeitige Ansteuerung
beider Kanäle, 8 Ω/Ohm)
0,05 %
• Ausgangsbandbreite: (8 Ω/Ohm, 0,05 %)
5 Hz – 40 kHz
• Frequenzgang: (CD, 1 W, 8 Ω/Ohms Last)
5 Hz – 100 kHz ±3 dB
• Dämpfungsfaktor: (8 Ω/Ohm, 20 Hz − 20 kHz)
100
• Eingangsempfindlichkeit/Eingangsimpedanz
PHONO (MC):
270 µV / 100 Ω/Ohm
PHONO (MM):
2,7 mV / 47 kΩ/kOhm
CD/LINE:
240 mV / 20 kΩ/kOhm
P. DIRECT IN:
1,7 V / 20 kΩ/kOhm
• Ausgangsspannung/Ausgangsimpedanz
PRE OUT:
1,7 V / 220 Ω/Ohm
• Maximal zulässiger Eingangspegel PHONO
(1 kHz)
MC:
15 mV
MM:
150 mV
• RIAA-Abweichung: (20 Hz – 20 kHz)
±0,5 dB
• Signal-Rauschabstand (IHF-A, 8 Ω/Ohm)
PHONO (MC):
75 dB (0,5 mV Eingang, 1 W Ausgang)
PHONO (MM):
86 dB (5 mV Eingang, 1 W Ausgang)
CD/LINE:
106 dB (2 V Eingang, Nennausgang)
• Klangregelung
BASS (50 Hz):
±10 dB
TREBLE (20 kHz):
±10 dB
• Spannungsversorgung:
230 V Wechselstrom, 50/60 Hz
• Leistungsaufnahme (EN60065):
220 W
• Leistungsaufnahme im Bereitschaftsmodus:
0,2 W
Änderung der technischen Angaben und des Designs zum Zwecke der Verbesserung ohne
Ankündigung vorbehalten.
Technische Daten
v A
Anschluss
5.1-Mehrkanal-Wiedergabe ······························ 12
Endverstärker ··················································· 14
Fernbedienungsanschlüsse ····························· 15
Flexibles Steuerbussystem (F.C.B.S.) ··············· 10
Lautsprecher ······················································ 8
Netzkabel ························································· 15
Recorder ···························································· 9
Vollständiger Stereo-Doppelverstärkermodus
(Bi-Amp) ····························································11
Vorverstärker ···················································· 14
Wiedergabegerät ··············································· 8
Anschlusskabel ···················································· 7
Auswählen der Eingangsquelle ·························· 16
Auswählen des Tonabnehmers: MM/MC ··········· 24
v E
Einschalten des Geräts ······································ 16
Einstellen der Lautstärke ···································· 16
Einstellen des Klangs ········································· 17
v F
Fehlersuche ························································ 20
Fernbedienung ····················································· 6
Einlegen der Batterien ······································· 2
v L
Lautsprecher-Impedanz ······································ 24
v R
Rückseite ····························································· 5
v S
Standby-Automatik-Modus ································· 19
v T
Tipps ··································································· 20
v U
Überlastschutz ··················································· 24
v V
Vorderseite ··························································· 4
Vorübergehendes Ausschalten des Tons ············ 17
v Z
Zubehör ································································ 1
Index
