Technische Daten
Nennausgangsleistung
(von 20 Hz bis 20 kHz/THD = 0,08, zwei Kanäle ausgesteuert): 150 W/ch, 8 Ω
180 W/ch, 6 Ω
Maximale effektive Ausgangsleistung
(ab 1 kHz, 6 Ω, 10 % zwei Kanäle ausgesteuert):
210 W/ch, 6 Ω
Ausgänge:
6 – 8 Ω
Frequenzgang (1 W, 8 Ω):
8 Hz – 100 kHz (±3 dB)
Dämpfungsfaktor:
100
Eingangsempfi ndlichkeit/-impedanz:
1.2 V / 22 kΩ (UNBALANCED)
2.4 V / 30 kΩ (BALANCED)
Signal-Rauschabstand (IHF-A):
105 dB
Spannungsverstärkungspegel:
29 dB
Versorgungsspannung:
AC 230 V, 50/60 Hz
Leistungsaufnahme:
880 W
Bereitschaftszustand:
0,4 W
Änderung der technischen Angaben und des Designs zum Zwecke der Verbesserung ohne Ankündigung
vorbehalten.
Index
v Ziffern
7.1-Kanal-Surround-Wiedergabe ··························· 5
9.1-Kanal-Surround-Wiedergabe ··························· 5
11.1-Kanal-Surround-Wiedergabe ························· 5
v A
Aktivieren des Bereitschaftsmodus ····················· 9
Anschluss
Asymmetrisch···················································· 6
Externes Steuergerät ········································· 8
Fernbedienung ··················································· 7
Netzkabel ··························································· 7
Symmetrisch······················································ 6
Audiokabel ···························································· 4
Automatische Standby-Funktion ·························· 9
v B
Beispielvariante eines Anschlusses ····················· 5
v E
Ein-/Ausschalten der Leuchtanzeige ···················· 9
Einschalten des Geräts ········································ 9
v F
Fehlersuche ························································ 10
v K
Kondensation ······················································· 2
v L
Lautsprecherimpedanz ······································· 10
Lautsprecherkabel ················································ 4
v P
PIN-Belegung bei XLR-Buchse ····························· 4
v R
Rückseite ····························································· 3
v S
Schutzschaltung ················································· 10
Symmetrisches Kabel ·········································· 4
v V
Vorderseite ··························································· 3
v W
Wechselt die angeschlossenen Eingänge ············ 4
v Z
ZONE2 ·································································· 5
ZONE3 ·································································· 5
Zubehör ································································ 1
