cube / piccolo Re:sound
12
Technica data
Warranty
Warranty covers a period of 60
months from the purchasing date.
First contact your dealer or any
service requirements. If he is unable
to assist, send your unit without
accessories to your national sales
organisation. In all cases, include a
detailed description.
Maintenance
The aluminium surfaces of the S
series and the lacquered surface of
the housing, should just be cleaned
using a damp cloth and then wiped
dry with a soft cloth.
Do not use any scouring powder.
cube piccolo
Principle fullrange 2-Way BR
Frequency range (IEC) 100 Hz -18 kHz 65 Hz - 20 kHz
Power Capacity 60 / 80 watts 60 / 100 watts
Impedance 4 ohms 4 ohms
Sensivity 2,83V/ 1m 84 dB 88,5 dB
Rec. amplifier power: 60 - 100 W 60 - 100 W
Dimensions
Height 98 mm / 3,86 inch 140 mm/ 5,5 inch
Width 98 mm/ 3,86 inch 140 mm/ 5,5 inch
Depth [without terminal screw] 98 mm/ 3,86 inch 140 mm/ 5,5 inch
Weight 0,8 kg/ 0,36 lb 1,8 kg/ 0,82 lb
Specifications are subject to change.
