6.3.2 DSUB ANALOG (PC)
BRIGHTNESS
Adjust the brightness of DSUB ANALOG without affecting AV’s brightness.
CONTRAST
Adjust the contrast of DSUB ANALOG without affecting AV’s contrast.
H POSITION
Adjust the horizontal position of the image
V POSITION
Adjust the vertikal position of the image
PHASE
Remove the noises. When phase value is wrong, the image has vertical lines especially in dot
on and off.
PIXEL FREQ.
Adjust the sampling frequency of DSUB ANALOG signal
COLOR
The tone of colour can be changed from reddish white to bluish white.
The individual colour components are also user customizable.
9300K
Change colour temperature: Red 4 / green 5 / blue 50
7300K
Change colour temperature: Red 5 / green 46 / blue 46
6500K
Change colour temperature: Red 40 / green 54 / blue 54
USER
User customizable (red, green, blue)
NOTE:
The colour temperature could be changed based on the LCD specification.
