Laney
LA12C
BLOCK DIAGRAM & SPECIFICATIONS
In order to reduce environmental damage, at the end of its useful life, this product must not be disposed of along with normal
household waste to landfill sites. It must be taken to an approved recycling centre according to the recommendations of the
WEEE (Waste Electrical and Electronic Equipment) directive applicable in your country.
This product conforms to the requirements of the following European Regulations, Directives & Rules:-
CE Mark (93/68/EEC), Low Voltage (72/23/EEC), EMC (2004/108/EEC),
RoHS (EU2002/95/EC), WEEE (EU2002/96/EC)
Supply Voltage
~100V, ~120V, ~220V, ~230V, ~240V 50/60Hz Factory Option
Mains Fuse
Not user changeable
Power Consumption
20W
Output Power Rating
12W
Loudspeaker
Custom Designed 6.5” Driver with Co-Axial tweeter
Features
Rugged construction
Headphone socket
Aux In (10K? Input impedance)
(Nominal 475mV Input level)
EQ
LO ±10dBu @ 80Hz, Mid ±8dBu @ 550Hz, HI ±10dBu @ 10KHz
Input
60mV I/P Sensitivity, Impedance 1M Ohm/47pF
Size
310 (12 1/4") * 281 (11") * 215 (8 1/2") (H*W*D)
Unit Weight
6.5 Kg (14.5 lb)
Packing Weight
7.6 Kg (16.8 lb)
INSTRUMENT
INPUT
AUX IN
EQ SECTION
CHORUS
GAIN
LO
MID
HI
CHORUS
LED
CHORUS
ON/OFF
POWER
AMP
HEADPHONE
SOCKET
INTERNAL CO-AXIAL
LOUDSPEAKER
