20 PSTD 800 A1
GB
JIGSAW PSTD 800 A1
Introduction
Congratulations on the purchase of your
new appliance. You have selected a high-
quality product. The operating instructions
are part of this product. They contain important
information on safety, use and disposal. Before
using the product, familiarise yourself with all
operating and safety instructions. Use this product
only as described and only for the specifi ed areas
of application. Please also pass these operating
instructions on to any future owner(s).
Proper use
This appliance is suitable for straight and curved
cuts as well as mitre cuts of up to 45° on angular
workpieces made of plastic, wood and light metal.
This appliance is exclusively intended for private
use in dry rooms. Observe the information on saw
blade types. Any other usage of or modifi cation
to the appliance is deemed to be improper usage
and carries the risk of serious personal injury.
The manufacturer accepts no responsibility for
damage(s) arising out of usage contrary to the
instructions specifi ed below.
Features
Stroke rate adjusting wheel
On/off switch lock button
On/off switch
Housing
Power cable
Extraction connector
Baseplate
Sliding shoe (removable)
Switch for sawdust blower
Pendulum stroke switch
Guide fence
Guide roller
Saw blade
Insertion openings (each incl. clamping screw)
Guard
Pivoting guard
Quick-release chuck
ON/OFF switch laser/working light
Clamping screw
Toothing
Allen key
Package contents
1 jigsaw incl. extraction connector
1 guide fence
1 operating manual
3 saw blades for woodwork
1 saw blade for metalwork
Technical details
Jigsaw: Parkside PSTD 800 A1
Rated voltage: 230 V ∼ 50 Hz
Rated input: 800 W
No-load speed: max. n
0
3100 min -1
Cutting depth: wood/metal: 80/8 mm
Pendulum stroke: 3 stages and fi ne cut
adjustment
Diagonal cuts: 0–45° left/right
Protection class: II/
Noise and vibration data:
Noise measurement determined in accordance
with EN 60745. The A-rated noise level of the
electric tool is typically:
Sound pressure level: 94 dB(A)
Sound power level: 105 dB(A)
Uncertainty K:
3 dB
Wear ear protection!
Evaluated acceleration, typically:
Hand/arm vibration a
h
= 8.6 m/s 2
Uncertainty K = 1.5 m/s 2
