22 PBH 1500 A1
GB
Operation
Select operational mode
Hammer switch:
♦ Turn the hammer switch to the required
symbol:
Hammer drilling = Hammer ON
Drilling = Hammer OFF
Function selector:
♦ Turn and hold the release button for the func-
tion selector switch and rotate the function
selector switch so that the required symbol
engages at the arrow mark.
Hammer drilling
Chiselling
NOTE
The following combinations are available:
► Hammer OFF + hammer drilling =
drilling
► Hammer ON + hammer drilling =
hammer drilling
► Hammer ON + chiselling = chiselling
► Hammer OFF + chiselling = no function
Preselecting rotational speed
You can use the rotational speed preselector ad-
justing wheel to preselect the rotational speed.
Work out the right setting with this practical test:
- high rotational speed: for hammer drilling/
chiselling in concrete or stone
- medium rotational speed: for drilling in steel
or wood
Switching on and off
Switching the appliance on:
♦ Press the ON/OFF switch .
Switching the appliance off :
♦ Release the ON/OFF switch .
Maintenance and Cleaning
WARNING! RISK OF INJURY! Switch
the appliance off and remove the
power plug before starting any
work.
■ The appliance must always be kept clean, dry
and free from oil or grease.
■ To clean the casing, use a soft dry cloth.
■ Clean the tool holder regularly:
♦ To do this, pull the locking sleeve backwards
and pull the dust protector cap off the tool
holder .
WARNING!
■ If the supply cord of this power tool is dam-
aged, it must be replaced by a specially
prepared cord available through the service
organization.
Disposal
The packaging is made from environmen-
tally-friendly material and can be disposed
of at your local recycling plant.
Do not dispose of power tools in
your normal domestic waste!
European Directive 2012/19/EU requires that
worn-out power tools are collected separately and
fed into an environmentally compatible recycling
process.
Your local community or municipal authorities can
provide information on how to dispose of the worn-
out appliance.
