5 PBH 1500 A1
GB
IE
CY
Appliance-specifi c safety instructions
for hammer drills
■ Wear ear protectors. Exposure to
noise can cause hearing loss.
■ Use auxiliary handle(s), if supplied with the
tool. Loss of control can cause personal injury.
■ Hold power tool by insulated gripping surfac-
es, when performing an operation where the
cutting accessory may contact hidden wiring
or its own cord. Cutting accessory contacting
a “live” wire may make exposed metal parts of
the power tool “live” and could give the opera-
tor an electric shock.
■ Wear a dust mask.
WARNING! TOXIC DUST!
► Working with harmful/toxic dusts results in
health hazards for the person operating the
appliance and for other persons in the area.
■ ATTENTION – SERVICE LINES! DANGER!
Take steps to ensure that you do not hit any
service lines (electricity, gas, water) when
working with the electric tool. If necessary,
check with a service line detector before you
start to cut or drill into a surface.
Original accessories/additional
equipment
■ Only use the accessories and additional
equipment that are specifi ed in the operat-
ing instructions and are compatible with the
appliance.
Initial operation
Additional handle
NOTE
► For safety reasons, you should only use this
appliance with the additional handle
attached.
♦ Remove the additional handle by turning it
clockwise direction.
♦ Turn the additional handle to the desired
position.
♦ Fix the additional handle in the new position
by turning it anti- clockwise.
Depth stop
♦ Open the wing screw .
♦ Insert the depth stop into the additional
handle .
♦ Ensure that the toothing on the depth stop is
facing upwards.
♦ Pull the depth stop out far enough for the
distance between the tip of the drill and the tip
of the depth stop to correspond with the
required drilling depth.
♦ Re-tighten the wing screw afterwards.
Tool/chuck:
♦ Pull the locking sleeve backwards and insert
the tool/chuck in the tool holder .
♦ Release the locking sleeve . This locks the
holder. Check that the tool is properly locked by
pulling it. The system has radial play because of
the design.
Removing tool/chuck:
♦ Pull the locking collar on the tool backwards.
NOTE
Tighten the drill in the wheel-rim chuck at the
same time. To do this, apply the chuck key to all
the 3 positions on the wheel-rim chuck and
tighten the tool (e.g. drill) at the same time.
WARNING!
► Do not use the wheel-rim chuck for ham-
mer drilling or chiselling!
