26 PHKS 1350 A1
GB
CIRCULAR SAW PHKS 1350 A1
Introduction
Congratulations on the purchase of your
new appliance. You have selected a high-
quality product. The operating instructions
are part of this product. They contain important in-
formation about safety, use and disposal.
Before using the product, familiarise yourself with
all operating and safety instructions. Use this product
only as described and only for the specifi ed areas
of application. Please also pass these operating
instructions on to any future owner(s).
Proper use
This circular saw (hereinafter "appliance") is
designed for longitudinal, cross and mitre cuts in
fi rmly supported solid wood, chipboard, plastics
and lightweight construction materials. Any other
uses of or modifi cations to the device are deemed
to be improper usage and may result in serious
physical injury. Not for commercial use.
Features
Safety lock-out
ON/OFF switch
Cutting depth scale
Allen key SW 6
Locking screw
Base plate
Guide fence slot
Wing screw for guide fence slot
Wing screw for cutting angle preselector
Cutting angle scale
Spindle lock
Auxiliary handle
ON/OFF switch laser
Laser discharge opening
Guide fence
Clamping fl ange
Clamping screw/plain washer
Blade guard
Release lever for the blade guard
Saw blade
Chip ejector
Vacuum adapter for dust extraction
Rotational speed preselector adjusting wheel
Battery compartment cover
Package contents
1 circular saw
1 guide fence
1 vacuum adapter for dust extraction
1 Allen key SW 6
2 saw blades
2 batteries
1 operating instructions
Technical details
Nominal power input: 1350 W
Rated voltage:
230 V ∼ 50 Hz
Idle speed: n
0
2.200–4.700 min -1
Saw blades: 1x Ø 190 mm x 2.5 mm x
Ø 20 mm, 24 teeth
1x Ø 190 mm x 2.5 mm x
Ø 20 mm, 48 teeth
Max. cutting depth: at 90°: wood 65 mm,
plastic 65 mm,
Protection class: II /
Noise and vibration data:
Noise measurement determined in accordance
with EN 60745 The A-rated noise level of the
tool is typically:
Sound pressure level: 94.25 dB(A)
Sound power level:
105.25 dB(A)
Uncertainty K: 3 dB
