19 PSBSA 18-Li A1
GB
Changing tools
Your cordless combi drill has a fully automatic
spindle lock
.
When the motor is stopped, the power train is
locked so that the chuck can be opened by turn-
ing
. After you have attached the desired tool
and tightened it by turning the chuck , you can
continue working. The spindle lock is automatically
released when the motor starts (ON/OFF switch
pressed ).
Selecting torque/operating mode
The torque selector allows adjustment of the torque
or selection between the drill setting and the
hammer drill setting .
♦ Select a low level for small screws or soft
materials.
♦ Select a high level for large screws, hard materials
or removing screws.
♦ Select the drill setting for drilling work by adjust-
ing the torque selection ring to the position .
♦ Select the hammer drill setting for hammer drilling
work by adjusting the torque selection ring to
the position .
2 speed gearbox
CAUTION!
► Only operate the speed selection switch
when the appliance is at a standstill.
Otherwise the appliance can be damaged.
In fi rst gear (speed selector switch in
position: 1)
you can reach a speed of approx. 440 rpm and
a high torque. This setting is suitable for all screw-
driving but also for the use of accessories.
In second gear (speed selector switch in
position: 2)
you can reach a speed of approx. 1650 rpm for
carrying out drilling work.
First use
Switching on and off
Switching on:
♦ To start the appliance, press and hold the ON/
OFF switch .
The LED work light illuminates when the
ON/OFF switch is depressed even lightly.
♦ This allows illumination of the work area in low
light conditions.
Switching off :
♦ Release the appliance's ON/OFF switch to
switch off the appliance.
Setting the rotational speed
Pressing the ON/OFF switch lightly provides a
low rotational speed. Increasing pressure increases
the speed.
NOTE
► The integrated motor brake ensures a quick
stop.
Changing the direction of rotation
♦ Change the direction of rotation by pressing the
rotational direction switch towards the left
or right.
Tips and tricks
Tip! This symbol indicates proper
behaviour!
♦ Before operation, check whether the screw or
drill bit is correctly positioned, i.e. centred in the
drill chuck.
♦ Screw bits are labelled according to their di-
mensions and their shape. If you are uncertain,
always check whether the bit fi ts tightly in the
screw head without any free play.
Torque:
♦ Smaller screws/bits can be damaged if you set
the torque or rotational speed too high.
