Florabest Z17770 - Handbuch (Seite 3)

3 GB/IE
Greenhouse
Q Introduction
Familiarise yourself with the product prior to assembly. Carefully
read the following assembly instructions and safety tips. Only use
the product as instructed and only for the indicated field of appli-
cation. Keep instructions in a safe place. Submit all documents to a third party
if distributing the product.
Q Proper Use
This product is designed for cultivating plants under controlled conditions.
Any use other than that described or any modification of the product is not
permissible and may result in injury and/or damage to the product. The man-
ufacturer is not liable for damage caused by improper use. The product is not
intended for commercial use.
Q Description of parts
A Corner plastic connector
B Plastic connector (for 4 tubes)
C Plastic connector (for 5 tubes)
D Plastic connector (cross shape)
E Plastic connector (for 3 tubes)
F Top pole (left)
G Top pole (right)
H Top pole (middle right)
I Upper vertical pole
J Lower vertical pole
K Horizontal pole
L Horizontal foundation pole with hole
M Horizontal connection pole
N Horizontal pole (entrance)
O Connecting wire
P Wire shelf
Q Ground spikes
R Rope
S Cover
Q Supply scope
4 x corner plastic connector
30 x plastic connector (for 4 tubes)
6 x plastic connector (for 5 tubes)
2 x plastic connector (cross shape)
4 x plastic connector (for 3 tubes)
3 x top pole (left)
2 x top pole (right)
1 x top pole (middle right)
22 x upper vertical pole
12 x lower vertical pole
24 x horizontal pole
4 x horizontal foundation pole with hole
22 x horizontal connection pole
4 x horizontal pole (entrance)
2 x connecting wire
8 x wire shelf
16 x ground spikes
4 x rope
1 x cover
1 x assembly instruction
Q Dimensions and materials
Dimensions: approx. 140 x 200 x 140 cm (w x h x d)
Materials
Frame:
Metal
Cover: Plastic
Safety advice
J WarnInG!
rISK OF LOSS OF LIFE Or aCCIDEnT
TO InFanTS anD CHILDrEn! Never leave children
unsupervised with the packaging material or the product. The
packaging material presents a suffocation hazard and there is a risk of
loss of life from strangulation. Children often underestimate danger.
Always keep the product out of reach of children.
m CaUTIOn! rISK OF InJUrY! Ensure that all parts are undamaged
and have been assembled appropriately. Risk of injury exists if assembled
incorrectly. Damaged parts can effect safety and function.
m CaUTIOn! Do not leave children unattended. The product is not a
climbing frame or toy. Make sure that nobody climbs or leans on the
product, particularly children. The product could become imbalanced
and tip up. This may result in injury and / or damage.
m CaUTIOn! rISK OF InJUrY! On no account should you assemble
or disassemble the product in a strong wind.
J Be sure to place the product on a solid, even surface providing a solid
footing.
J Protect the product from strong winds and storms. Place the product in a
place that is sheltered from the wind.
J In heavy snow the product may collapse. Accumulated snow must be
melted or shaken off periodically.
J Regularly check that all joints are in good condition; check that the cover S
and the ground spikes Q are firmly in place.
J Do not put pressure onto the product and ensure even weight distribution
on the shelves. The product may otherwise be overbalanced and tip.
J
5 kg
Take care not to exceed the maximum weight of 5 kg per shelf
otherwise this may result in a risk of injury and / or damage to
the product.
J Always have the lowest shelf filled prior to the upper ones. Always try to
lower the center of gravity of the product when filling up the shelves.
J CaUTIOn! DanGEr OF POISOnInG anD DanGEr OF
DaMaGE TO PrOPErTY! Do not light fires inside the product and
keep product away from heat sources.
J Do not rely on the product as your shelter from extreme weather.
Q assembly
Make sure that the product is only assembled by competent persons.
j Assemble the product in line with Figures 1 to 6.
Q Cleaning and Care
j Clean the product with a dry, non-fluffing cloth.
j Use a damp cloth and if necessary a mild detergent to remove more
stubborn dirt.
j Do not under any circumstances use abrasive or corrosive cleaning agents.
Q Disposal
The packaging is made entirely of recyclable materials, which you
may dispose at local recycling facilities.
Contact your local refuse disposal authority for more details of how to
dispose of your worn-out product.
