Florabest FHM 38 A1 - Handbuch (Seite 6)

6
GB IE
Functionality
The lawn mower has a reel blade cylinder
containing 5 bow-shaped blades. Its cut-
ting height is infinitely adjustable, and its
wheels turn smoothly.
Read the sections below to learn more
about each operating element’s function.
Scope of Delivery
Carefully unpack the appliance and check
that it is complete:
- Mower
- Handle top
- Handle bottom
- 2 centrepieces
- 4 screws
- 4 nuts
- Machine key
- Tool holder with metal strip (feeler
gauge)
- Instruction manual
Fit the Handle
1. Press both ends of the handle
bottom (6) together and insert
them vertically through the han-
dle holder (7) on the machine.
2. Push the holes at the ends over
the two holder bolts (16).
3. Use the screws and wing nuts
from the package to mount the
top part of the handle (1) on the
two cross bars (2).
4. Use the screws and wing nuts
from the package to mount the
cross bars (2) on the bottom part
of the handle (6).
The two centre bars can be se-
cured in two positions to adjust the
handle bar to your height.
5. Mount the tool holder (5) from
the package to the bottom part
of the handle (6) and snap on
the machine key (3) to it.
Adjust the Cut Height
The cut height is infinitely adjustable from
14 – 43 mm:
1. Loosen the locknuts (12) on both
sides of the machine.
2. Place one foot on the castors (9)
and set the desired cut height
with both hands on the adjusting
handles (14).
Ensure that the machine is set to
the same height on both sides.
3. Retighten the locking screws (12).
Set the cut height no lower than to
where the blade cylinder does not
touch the ground even where it is
uneven.
Working Instructions
Before each use, check the ma-
chine for obvious defects, such
as loose, worn or damaged parts.
Check that all nuts, bolts and
screws are sitting firmly.
Regular mowing stimulates the stronger
formation of leaves in the grass as well
as allowing weeds to die off at the same
time. Thus, the lawn becomes thicker
each time it is mowed and a lawn with
even resilience is produced.
• Run the machine at walking pace, in
strips that are a straight as possible.
For seamless mowing, the strips
