Using the loppers (see Fig. D)
Loosen the retaining pin of the loppers.
Pull the plastic handle down to make a cut.
As soon as you have finished working with the loppers, secure with the
retaining pin.
Setting the cutting angle (see Fig. E)
Turn the rotating disc clockwise and choose one of the seven available
angle adjustments.
Turn the rotating disc anticlockwise to fix it after the angle has been adjusted.
Note: Please ensure that the turning disc is fixed, before starting work.
Extending the telescopic pole (Figure F)
Loosen the retaining pin to be able to extend the telescopic pole.
Extend the telescopic pole to the desired length.
Note:
The maximum length of the combination loppers is 2.77 m, the
minimum length is 2 m.
Fasten the retaining pin well.
Note: Please ensure after each adjustment that the retaining pin is well secured.
