Florabest FBM 450 A1 - Handbuch (Seite 36)

36
GB
The correct cutting height is around
30 – 45 mm for an ornamental lawn and
around 40 – 65 mm for a utility lawn.
Select a greater cutting height for
the first cut of the season.
Emptying the Grass Collec-
tion Box
Fill Level Indicator:
The fill level indicator ( 22) attached to
the side of the grass collection box ( 24)
shows when the grass collection box is full.
GO
STOP
Fill level indicator open:
Grass collection box empty
GO
STOP
Fill level indicator closed:
Grass collection box full
1. Stop the engine and wait until
the blade is stationary.
2. Lift the rear impact protection
(22) and remove the grass collec-
tion box (20).
3. Empty (see “Disposal/Environ-
mental protection“) and reassem-
ble the grass collection box (20).
Cleaning and
Maintenance
Have any repair and mainte-
nance work not described in
these instructions carried out
by a specialist workshop. Use
only original Grizzly replace-
ment parts. Risk of accidents!
Carry out maintenance and
cleaning work strictly with
the engine switched off and
spark plug connectors re-
moved. Risk of injury!
Allow the equipment to cool
before any maintenance and
cleaning work. Elements of
the engine are hot. Risk of
burning!
Wear gloves when handling the
blade.
For cleaning and maintenance
work, also observe the Briggs &
Stratton instruction manual supplied.
We recommend contacting an au-
thorised Briggs & Stratton dealer for
maintenance work on the engine
(see Briggs & Stratton dealer list).
Cleaning and General Main-
tenance Work
Tilt the device back for cleaning
and maintenance jobs at the bottom
side so that the spark plug faces
upwards.
Make sure that a second person
holds the device because there is a
danger of tipping backwards.
Do not tilt the equipment sideways
or forwards. Operating fluids could
leak out and the engine could be
damaged.
• Always keep the equipment clean. To
clean, use a toothbrush or cloth but no
corrosive cleaning agents or solvents.
Do not use water to clean the engine
as it could contaminate the fuel system.
• After mowing, remove plant remains
that are stuck to the equipment by using
a piece of wood or plastic. Clean the
vent holes ( 11), ejection hole and
