Introduction / Safety information
Tyre stand
 Introduction
Please familiarise yourself with the product
prior to assembly. Carefully read the
following assembly instructions and safety
tips. Only use the product as described and for the
specified applications. Store these instructions in a
safe place. If passing this product on to a third party
also include all documents.
 Intended use
The tyre stand is intended for the storage of wheel
rims with or without tyres. Any use other than the
aforementioned or any product modification is prohib-
ited and can lead to injuries and / or product damage.
The manufacturer is not liable for any damages
caused by any use other than its intended purpose.
This product is not intended for commercial use.
Children and persons who are unable to operate
the equipment safely because of their physical, sen-
sory or mental capacities or their inexperience or
lack of knowledge must not use the equipment.
 Description of Parts
1 Central linking piece
2 Screws
3 End rod section (with plug)
4 Down rod section (without plug)
5 Extension legs
6 Pin
7 Storage container (2 parts)
8 Plate
9 Screws
10 Tread depth gauge
11 Air pressure gauge
12 Tyre protection cover
13 Tyre chips, 4 different colours
14 Hexagon wrench
 Technical data
Suitable for all currently available car rims up to
18 inches (45.72 cm).
Suitable for all common car wheel rims with tyre
widths up to 225 mm.
Material: steel, aluminium,
PP (polypropylene)
Total height
(without container): ~1,13 m
Weight (without
accessories):
~2,2 kg
 Accessories
Tyre protection cover
With Velcro fastening
Tyre chips
In 4 different colours. Labelling: front left, right
front, left rear, right rear
Air pressure gauge
For easy measurement of air pressure. Measure-
ment range: 0.7 – 3.5 bar / 10 – 50 psi
Tread depth gauge
Measurement range: 0 – 20 mm; shows statutory
minimum tread depth (1.6 mm) and recommended
tread depth for winter tyres (4 mm).
Storage container
For practical storage of assembly equipment.
Safety information

Do not tilt the tyre stand!
WARNING! POTENTIAL HAZARD!
LOW RISK OF INJURY TO PERSONS!
DANGER OF TIPPING!

Place the tyre stand only on a level, flat and
solid surface. The base must not slope, as the
stability of the rack cannot then be guaran-
teed. (Use spirit level to check.)

The tyre stand may not be used for any other
purpose since this could cause injury.
