- 3 -
Items supplied
1 x Trolley Jack
2 x Lifting rods
1 x Carrying grip
1 x Operating instructions
Description of the appliance
q Lifting lever
w Loading plate
e Carrying grip
r Release valve
t Lifting lever collet
y Securing points for the carrying grip e
u Adjusting screw
Preparatory steps
1. Attach the carrying grip e to one of the two
securing points y . Ensure that the carrying grip
e is not overloaded and breaks.
2. Push the lifting levers q into each other.
Turn them until they are secured against being
pulled apart.
3. Place the lifting levers q onto the release valve
r at the front.Turn it clockwise to close it
completely.
4. Now place the lifting levers q in the lifting lever
collet t .
5. Turn the lifting levers q clockwise until they are
secure against being pulled out.
6. On the first utilisation or after an extended
period of non-usage, first pump the Trolley Jack
without any loading (6-7 pump movements).
This distributes the hydraulic oil evenly again
iinside the device.
Raising the vehicle

Important: Refer to the vehicle owner's
handbook to find out where the lifting points are
located. To avoid damage, the vehicle may only
be raised at these places.
1. Push the loading plate w to exactly in the
middle below the lifting point.

Note: Ensure that you place the vehicle jack in
such a position that the lifting levers
q are not
under the vehicle.
2. To start, only pump until the loading plate w is
just touching the lifting point. This permits you to
make corrections if needed.
3. Now raise the vehicle until you have sufficient
clearance to position the axle stands.
4. Permit the vehicle to drop onto the axle stands in
that you slowly open the release valve r by
turning it in an anti-clockwise direction.
Lowering the vehicle
1. First raise the vehicle a little to remove the axle
stands.
2. Then, with the lifting lever q , slowly turn the
release valve r (anti-clockwise) and carefully
allow the vehicle to descend.
3. As soon as the Trolley Jack is removed from
under the vehicle, the loading plate w can be
completely pressed down with the foot.
