Pumping oil out – Ultimate Speed UOP 12 A1 Benutzerhandbuch
Seite 20
17
UOP 12 A1
GB
Pumping oil out
♦
Before starting to pump oil out, let your vehicle engine warm-up for 5 - 10
minutes (oil temperature 40°C - 60°C). This reduces the viscosity of the oil
and it can then be pumped out more effi ciently.
♦
Switch the vehicle motor off .
♦
Roll out the suction hose (Ø 6 mm)
7
and the discharge hose (Ø 12 mm)
8
.
♦
Insert the suction hose (Ø 6 mm)
7
into the dipstick opening of your vehicle.
Insert it carefully down to the lowest point of the oil sump.
♦
Use a suitable container to collect the old oil and insert the discharge hose
(Ø 12 mm)
8
into the container.
♦
Ensure that the on/off switch
2
is in the position 0 (off ).
♦
First, connect the red positive-pole connection terminal (red)
3
to the
positive-pole (+) of the car battery.
♦
Then connect the black negative-pole connection terminal (black)
4
to the
negative-pole (-) of the car battery.
♦
Place the on/off switch
2
at position I (On) to switch the oil suction pump
on.
♦
Pump the oil out of the engine/the oil sump.
♦
Place the on/off switch
2
at the position 0 (Off ) when no more oil fl ows
from the engine/the oil sump. Do not leave the oil suction pump
running
if it is not pumping oil.
♦
Do not let the oil suction pump
run for longer than 30 minutes at a time.
♦
Refi ll the engine with fresh oil as directed in your vehicle manufacturer's
instructions. Check the oil level with the dipstick.
♦
Clean the oil suction pump after the job is done by pumping a little fresh oil
through it.
♦
Dispose of the used oil as per the statutory regulations in your country
(see also the chapter Disposal).
♦
Loosen the hose clamps
9
and remove the suction hose (Ø 6 mm)
7
and
the discharge hose (Ø 12 mm)
8
from the oil suction pump. Store all parts
at a dry, clean and dust-free location.
