- 7 -
Note:
The back-up batteries must be checked at least once
per year and, if necessary, exchanged for new ones.
Fixing the kitchen radio beneath a wall cabinet
With the supplied mounting plate q you can fix the kitchen
radio below, for example, a kitchen wall cabinet:
1. Determine a suitable location for the kitchen radio.
2. Press the two retaining levers on the back of the appliance
down. Push the mounting plate q back and remove it.
3. Hold the mounting plate q under the installation location.
Thereby, the front edge of the mounting plate q should
be approx. 3.5 cm behind the front of the kitchen cabinet..
4. Mark the four points for the drillholes with a pencil.
5. Using a spike, make a small depression at the marking
points. Firmly secure the mounting plate q with the sup-
plied screws.
6. Hold the kitchen radio slanted, with the two recesses in
the retaining lugs on the mounting plate q.
Press the kitchen radio upwards until it audibly engages.
Disassembly
To disassemble the kitchen radio, press the two retaining •
levers at the rear of the appliance downwards. Then pull
the radio out to the front and remove it.
Unscrew the screws and remove the assembly plate •
q
.
Setting up the kitchen radio
Do not set the kitchen radio up without the mounting plate
q
. Otherwise the speakers are covered and the sound is
scarcely audible.
To fit the kitchen radio with the supplied mounting plate q:
1. Simultaneously press the two retaining levers on the back
of the appliance down.
Push the mounting plate q back and remove it.
2. Push the two retainer lugs on the mounting plate q into
the recesses on the lower rear side of the kitchen radio.
3. Press the mounting plate q firmly in the direction of the
appliance rear until it audibly engages.
