Inserting the batteries
SPUV 90 A1:
You require 2 x 1.5 V batteries of the type Micro/AAA/LR03 and 1 battery
of the type CR 2032 (all items supplied).
1. Open the cover of the battery compartment k at the rear of the device.
2. Insert the batteries into the battery compartment k , paying heed to the
polarity markings shown in the battery compartment k .
3. Close the cover of the battery compartment k , such that it engages firmly.
SPUH 90 A1:
You require 2 x 1.5 V batteries of the type Micro/AAA/LR03 and 1 battery
of the type CR 2032 (all items supplied).
1. Open the cover of the battery compartment k on the underside of the
device.
2. Insert the batteries into the battery compartment k , paying heed to the
polarity markings shown in the battery compartment k .
3. Close the cover of the battery compartment k , such that it engages firmly.
Placing
• Place the projection clock onto a level surface.
• Position the projection clock such that the projection lens
q is directed onto
an empty surface. The distance from the projection lens to the projection
area (ceiling or wall) must lie between 0,4 m and 3 m.
