56 GB / IE
Inserting the bobbin
Attention:
Turn power switch to off ("O").
When inserting or removing the bobbin, the
needle must be fully raised.
1. Open the hinged cover.
2. Hold the bobbin case with one hand.
3. Insert the bobbin (2) so that the thread
runs in a clockwise direction (arrow). (3)
4. Put the thread under the tension spring.
5. Hold the bobbin case by the hinged latch.
6. Insert it into the shuttle.
1
2
3
4
5 6
a
Getting ready
Winding the bobbin
a. Spool pin felt
Place an empty bobbin on spindle.
Take the thread from the spool through the
guide to the bobbin.
Wind the thread a few times by hand around
the empty bobbin in a clockwise direction.
Push the bobbin to the right towards the
bobbin winding position.
Press the foot control gently. The bobbin
will stop winding when it is full. Push the
bobbin to the left to "sewing position" and
remove it.
When the bobbin winder spindle is in
"bobbin winding" position, the machine
will not sew. To start sewing, push the
bobbin winder spindle to the left (sewing
position).
Note:
