7 SLB 1.2 B2
GB
CY
Handling and use
This section provides you with important information on handling and
using the device.
System requirements
▯ Computer with sound card and USB connection
or
▯ audio device with audio output (3.5 mm jack plug) and USB
connection (alternatively with external USB power supply).
Connecting the loudspeaker
♦ Ensure that the rotary switch 4 is in the “OFF” position.
♦ Plug the 3.5 mm jack plug 8 into the line out or headphone
socket of your audio device (e.g. notebook, MP3 player).
The audio signals are transmitted via this connection.
♦ Plug the USB plug 9 into a USB socket of your audio device
(alternatively into the USB socket of an external USB power
supply). The mains adapter should have the following speci-
fi cations: 5 V
, min. 500 mA. The power supply for the
loudspeaker 6 is provided via this connection.
NOTE
► The loudspeakers
6
do not work without a USB connection!
Switching on/off and adjusting the volume
♦ Turn the rotary switch 4 clockwise until a click is heard in
order to switch the loudspeakers 6 on.
♦ Turn the rotary switch
4
further in a clockwise direction to
increase the volume.
♦ Turn the rotary switch 4 anticlockwise to decrease the volume.
♦ Turn the rotary switch 4 anticlockwise until a click is heard
(OFF position) in order to switch the loudspeakers 6 off .
Switching the light on and off
♦ Turn the LIGHT switch to the “ON” position in order to
switch the loudspeaker
6
light on.
♦ Turn the LIGHT switch to the “OFF” position in order to
switch the loudspeaker 6 light off .
