- 4 -
Working with the floor sweeper

Caution:
• Never use the device with the dirt container
removed. The dirt would only be swirled around!
• Keep end of rotating brush, wands and other
openings away from your face and body. Risk of
injury!
• Press the switch to start the rechargeable bat-
tery floor sweeper. Press again to switch off the
device.
• Guide the rechargeable battery floor sweeper
over the floor.
• You can leave the broomstick  locked in verti-
cal position during work interruptions.

Note:
With some types of carpet the rechargeable battery
floor sweeper could rattle or bounce. In this case
work slowly and in the opposite direction.
Cleaning

Caution:
Do not clean the appliance while charging it. Always
disconnect the battery charger from the mains po-
wer socket before cleaning the appliance!
To clean the housing:
Wipe the housing of the appliance with a damp
cloth. If necessary, use a mild detergent on the
cloth.
Ensure that the appliance is completely dry before
reconnecting it with the battery charger.
How to clean the dirt container:
To maintain the efficiency of the rechargeable
battery floor sweeper, empty the dirt container after
every use.
• Press the unlocking locking release button
 of
the dirt container to detach it from the device.
• Remove the dirt container from the appliance
horizontally with a downward movement.
• Empty the dirt container and re-insert.
How to clean the brush:
If the brush roller cannot be turned any longer
because of accumulated coarse dirt or threads,
proceed as follows:
• Turn over the rechargeable battery floor swee-
per and hold it so that the flat side with the brush
roller faces you.
• Remove the small cover  on the right-hand
side.
• Loosen the drive belt by pushing it to the right.
• Lift the brush roller on the right-hand side and
remove the guide attachment with washer .
• Now pull the brush roller from the device to the
right-hand side.
• Remove the dirt (on both sides of the bristle) and
clean the brush.
After cleaning, proceed as follows to re-install the
brush roller:
• Insert the drive belt in the compartment and
place it around the motor drive pulley.
• Place the washer on the guide attachment with
washer  and insert the brush roller into the left
guide channel.
• Pull the drive belt over the guide attachment with
washer  and re-insert the brush roller into the
right channel.
• Now pull the drive belt over the drive cog of the
brush roller.
• Fit the brush cover  by first introducing the
lower lugs in the recesses and press the cover
in at the top.

Caution:
• Ensure that the device is not inadvertently
switched on with the dirt container removed or
while cleaning the brush. Risk of Injury!
• Do not clean the device during the charging
process. Risk of Injury!
