4

2. Names of parts

(see fold-out page)

1 Rest for remote control
2 Control panel
3 Warning symbol - “Do not cover”
4 Air outlet
5 Display
6 Air inlet
7 Feet
8 Temperature sensor
9 Mains switch
10 Handle
11 Selected heating level display
12 "Fan" symbol
13 "Frost protection" symbol

14 Selected unit of measurement display
15 Fan button
16 Increase temperature
17 Reduce temperature
18 Timer button
19 Running time display
20 Set temperature display
21 Measured temperature display
22 On/Off button
23 Infrared receiver for remote control
24 Button for selecting unit of measurement
25 Button for selecting the heat setting

3. Technical data

Power supply:

220 - 240 V

~

/50 Hz

Maximum power:

2,300 watts

Protection class:

I

Batteries for remote control: 2x type AAA/LR03 1.5 V
Ambient conditions:

0 °C to +25 °C, max. 85 % relative humidity

4. Safety information

4.1 Terms used

The following signalling terms are found in
these Operating Instructions:

Warning!
High risk. Disregarding the
warning may cause injury to life
and limb.

Caution!
Medium risk. Disregarding the warning may
cause damage to property.

Note:
Low risk. Circumstances that should be taken
into account when dealing with this
appliance.

4.2 General information

• Before using the appliance, be sure to

read these Operating Instructions
carefully. They are a component part of
the appliance and must be available at
all times.

RP90866 Konvektor LB6so Seite 4 Dienstag, 2. Juli 2013 3:39 15
