SilverCrest SLS 2200 A1
10 - English
Overview of controls and button functions
An illustration of the items and controls and their corresponding numbers can
be found on the inside page of the fold-out cover of this user manual. You can
keep this page folded out whilst reading the different chapters of this user
manual. This allows you to refer to the relevant controls at any time.
1 Solar panel
2 Output voltage selector switch (5V, 7.5V or 9.5V)
3 Output voltage LEDs
4 DC-OUT socket (to connect the device to be charged)
5 Solar LED
6 ON/OFF pushbutton
7 Battery capacity LEDs
8 IN socket (to connect a PC or USB power adapter)
