Inserting the battery
1. Open the battery compartment 7 at the rear of the
Ultrasonic Distance Meter.
2. Place the 9 V block battery onto the contacts.
Pay heed to the correct polarity.
3. Lay the 9 V block battery into the battery compartment 7.
Warning:
Ensure that the wires are not trapped in any way. This could
irreparably damage the appliance.
4. Close the battery compartment 7. The battery
compartment lid must audibly engage.
Measuring distances
1. Switch the appliance on by pressing the button
ON/OFF 0.
2. If necessary, press the MODE 9 button several times
until the indicator (distance measurement)
appears in the display.
3. To switch between metric (Meter M) and Anglo-American
(Feet‘/Inch’’) measurement units, press the button
FT/M 4.
4. Hold the appliance upright towards the wall to which
you wish to measure the distance. The ultrasound sender/
receiver 2 must be at a right-angle to the wall. For this,
use the spirit level 8. The bubble in the glass 8 must
stand between the marking lines (see Fig.1).
5. Press the button READ q briefly. A laser point is projected
and an acoustic signal sounds. Hold the appliance in
this position until the measured distance appears in the
display w.
Note:
Measurements start at the measurement point 6 ! Should the
measurement lie outside the measurement range, "Err" or
an illogical number appear in the display. The measurement
range lies between 0,6 m (ca. 2´) and 16 m (ca. 53´).
