TA Triumph-Adler DC 6025 - Handbuch

QUICKGuide
DC 6025P/DC 6025/DC 6030
QUICKGuide
DC 6025P/DC 6025/DC 6030
For more details refer to the Operation
Guide on the co-packed CD-ROM.
For more details refer to the Operation
Guide on the co-packed CD-ROM.
➊ Press SEND .
➋ Press FUNCTIONS .
➌ Choose the items to be changed by
opening the related submenu.
➍
Confi rm with CLOSE .
If the documents are still fed, press STOP .
➊ Press STATUS/JOB CANCEL .
➋ Press SEND JOB STATUS .
➌ Choose the job to be cancelled and press
CANCEL .
➍ Confi rm with YES .
Communication is cancelled.
➊ Press STATUS/JOB CANCEL .
➋ Press SEND JOB LOG .
➌ The result is displayed.
➍ Press to display more details of the
selected transmission.
➊ Press FAVORITES .
➋ Select a favorite.
➌ Make the desired settings.
➍ Confi rm the settings and start the job.
Cancelling
sending
job
Check
transmission
result
Using
Favorites
Scan
settings
➊ Place the originals on the platen or in the
document processor.
➋
Press SEND .
➌ Enter the destination address.
From the address book:
Press ADDRESS BOOK . Press the checkbox to
select the desired destination from the list.
Press , to fi nd the destination. Enter the
name you search for. Confi rm with OK .
You can also press MENU to perform a more
detailed search.
You may choose multiple destinations.
Enter an e-mail address:
Press E-MAIL . Enter the e-mail address on the
touch screen. After that press OK .
If you want to send the e-mail to several
destinations press ADD DEST. .
Enter a fax number:
Press FAX on the touch screen. Press ADD
DEST. . Enter the fax number in the destination
fi eld.
➍
To start transmission press START .
Sending
Print operation Copy operation
Note: To activate the private printing from
the PC, select the JOB tab in the printer driver
and click PRIVATE PRINT . The section JOBNAME
allows you to type in your name directly.
➊
Press DOCUMENT BOX .
➋ Press JOB BOX .
➌ Press PRIVATE PRINT .
➌ Select the creator of the private print job.
➍ Select the document to be printed from the
list. If the document is password protected,
type in the PIN with the TEN PAD keys.
➎ Press PRINT to start printing.
Note: By pressing jobs can be cancelled.
➊ Place the originals on the platen or in the
document processor.
➋
Press COPY .
➌ Enter the number of copies with the
TEN PAD keys.
Duplex
Press DUPLEX on the touch screen and select
the desired function.
Changing paper source
Press PAPER SELECTION . Choose the desired
paper format. When using special sizes select
the MP tray. Confi rm your selection with OK .
Finishing (optional)
Press FUNCTIONS on the touch screen and then
STAPLE . Choose the desired fi nishing.
Reducing/Enlarging (Zoom)
Press ZOOM on the touch screen. Select the
original format and the target format or
choose the zoom factor.
Paper output
Press FUNCTIONS and then PAPER OUTPUT .
Select a tray and confi rm with OK .
All of above optional settings have to be
confi rmed with OK .
You may choose additional settings by pres-
sing FUNCTIONS from the main menu.
➍ Press START and the copy starts.
➊ Press STATUS/JOB CANCEL .
➋ Press PRINT JOB STATUS .
➌ Select the job you wish to cancel and press
CANCEL .
➍ Confi rm with YES .
Job is cancelled.
Private
printing
Prepare copy
Optional
Settings
Cancel print
job
Sending
