2 Phonitor One d
Read the security advices on page 6!
Read the installation instructions of the included
external power supply on page 8.
Make sure that the power switch on the rear is set
to Off (Off = out position / ON = in position).
Connect the included power supply to the DC input
and an appropriate mains socket outlet.
Turn down volume.
Connect your headphone to the headphone output.
Connect your analog sources to the line inputs.
Connect your computer or mobile device to the
USB input.
Connect the line out to the inputs of your analog
audio device to benefit from the 32-bit Velvet
Sound™ DA converter.
The Line Out has always unity gain – it is not controlled by the volume
knob.
Switch the Phonitor One d on by pressing the
power button.
Choose an input.
Set the volume and the crossfeed to taste.
Have fun!
More information: SeriesOne.spl.audio
9
10
11
12
13
1
2
3
4
5
6
7
8
