4 Marc One
Analog inputs & outputs; 6.35 mm (1/4") TRS Jack (balanced), RCA
Input gain (max.) +22.5 dBu
Line Input 1 (balanced): Input impedance 20 kΩ
Line Input 1: Common mode rejection < 60 dB
Line Input 2 (unbalanced): Input impedance 10 kΩ
Output gain (max.): Speaker Outputs (600 Ω) +22 dBu
Line Output (unbalanced): Output impedance 75 Ω
Speaker Output 1 (balanced): Output impedance 150 Ω
Sub Output low filter none (full range)
Sub Output (balanced): Output impedance 150 Ω
Speaker Output 2 (unbalanced): Output impedance 75 Ω
Frequency range (-3dB) 10 Hz - 200 kHz
Dynamic range 121 dB
Noise (A-weighted, 600 Ω load) -99 dBu
Total harmonic distortion (0 dBu, 10 Hz – 22 kHz) 0.002 %
Crosstalk (1 kHz) < 75 dB
Fade-out attenuation -93 dB
USB, 32-Bit AD/DA
USB (B), PCM sample rates
44.1/48/88.2/96/176.4/192/
352.8/384/705.6/768 kHz
USB (B), DSD over PCM (DoP),
sample rates (playback only) 2.8 (DSD64), 5.6 (DSD128), 11.2
(DSD256) MHz
0 dBFS calibrated to 15 dBu
Noise (A-weighted, 44.1/48 kHz
sample rate)
-113 dBFS
THD + N (-1 dBFS, 10 Hz – 22 kHz) 0.0012 %
Dynamic range (44,1/48 kHz
sample rate)
113 dB
Specifications
