English
How to Use Wise CFexpress
Type B Memory Card
Before operating this media, please read this manual thoroughly, and retain it for future reference.
Components
Wise CFexpress Type B Memory Card
Quick Start Guide
How to connect
Select the device compatible with the Wise CFexpress Card Reader.
Connect one end of the cable to the device and the other end to
the reader with the card insert.
Tech Specs
Model
Capacity 1
Interface
Maximum read 2
Maximum write 2
Size
Weight
Operating voltage
Operating temperature
Storage temperature
PCIe Gen3 X2
1700 MB/s
1550 MB/s
29.6 x 38.5 x 3.8 mm
10 g
3.3 V
14˚F to 158˚F (-10˚C to 70˚C)
-4˚F to 185˚F (-20˚C to 85˚C)
1700 MB/s
1050 MB/s
1700 MB/s
1550 MB/s
CFX-B128
128GB
CFX-B256
256GB
CFX-B512
512GB
1 Some of the listed storage capacity is used for formatting and other purposes and is not available
for data storage. 1GB = 1 billion bytes.
2 Speeds based on internal testing. Actual performance may vary.
Caution
Wise shall not be responsible for any damage to or loss of recorded data.
Recorded data may be damaged or lost in the following situations.
If you remove this media or turn off the power while formatting, reading or writing data.
If you use this media in locations subject to static electricity or electrical noise.
