Anhang
(5 minutes for each step).
~XX107 n
7E 30 30 31 30 37 20 a 0D Sleep Timer (min)
n = 0 (a=30) ~ 995 (a=39 39 35)
(30 minutes for each step)
.
~XX114 1
7E 30 30 31 31 34 20 31 0D
Power Mode(Standby)
Active (<=0.5W)
~XX114 0
7E 30 30 31 31 34 20 30 0D
Eco. (0/2 for backward compatible)
------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX109 1
7E 30 30 31 30 39 20 31 0D
Lamp Reminder
On
~XX109 0
7E 30 30 31 30 39 20 30 0D
Off (0/2 for backward compatible)
~XX110 1
7E 30 30 31 31 30 20 31 0D
Brightness Mode
Bright
~XX110 2
7E 30 30 31 31 30 20 32 0D
Eco
~XX110 5
7E 30 30 31 31 30 20 35 0D
Power
~XX326 n
7E 30 30 33 32 36 20 a 0D
Power
350W/340W/330W/320W/310W/300W/290W/280W
(n=0/n=1/n=2/n=3/n=4/n=5/n=6/n=7/n=8)
~XX111 1
7E 30 30 31 31 31 20 31 0D
Lamp Reset
Yes
~XX111 0
7E 30 30 31 31 31 20 30 0D
No (0/2 for backward compatible)
------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX112 1
7E 30 30 31 31 32 20 31 0D Reset
Yes
------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX99 1
7E 30 30 39 39 20 31 0D
RS232 Alert Reset
Reset System Alert
~XX210 n 7E 30 30 32 30 30 20 n 0D Display message on the OSD n: 1-30 characters
-----------------------------------------------------------------------------------------------------------------------------------------------------------
SEND to emulate Remote
~XX140 10
7E 30 30 31 34 30 20 31 30 0D
Up
~XX140 11
7E 30 30 31 34 30 20 31 31 0D
Left
~XX140 12
7E 30 30 31 34 30 20 31 32 0D
Enter (for projection MENU)
~XX140 13
7E 30 30 31 34 30 20 31 33 0D
Right
~XX140 14
7E 30 30 31 34 30 20 31 34 0D
Down
~XX140 15
7E 30 30 31 34 30 20 31 35 0D
Keystone +
~XX140 16
7E 30 30 31 34 30 20 31 36 0D
Keystone –
~XX140 17
7E 30 30 31 34 30 20 31 37 0D
Volume –
~XX140 18
7E 30 30 31 34 30 20 31 38 0D
Volume +
~XX140 19
7E 30 30 31 34 30 20 31 39 0D
Brightness
~XX140 20
7E 30 30 31 34 30 20 32 30 0D
Menu
~XX140 21
7E 30 30 31 34 30 20 32 31 0D
Zoom
~XX140 28
7E 30 30 31 34 30 20 32 38 0D
Contrast
~XX140 47
7E 30 30 31 34 30 20 34 37 0D
Source
------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
SEND from projector automatically
------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
232 ASCII Code
HEX Code
Function
Projector Return
Description
------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
when Standby/Warming/Cooling/Out of
Range/Lamp fail/Fan Lock/Over Temperature/
Lamp Hours Running Out/Cover Open
INFOn n : 0/1/2/3/4/6/7/8/ =
Standby/Warming/Cooling/Out
of Range/Lamp fail/Fan
Lock/Over Temperature/Lamp Hours Running Out/Cover Open
------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
READ from projector
------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
232 ASCII Code
HEX Code
Function
Projector Return
Description
~XX121 1
7E 30 30 31 32 31 20 31 0D Input Source Commands
OKn
n: 0/1/2/3/4/5/7/10/15 =
None/DVI/VGA1/VGA2/S-Video/Video/BNC/HDMI/Component/DisplayPor
t
~XX122 1
7E 30 30 31 32 32 20 31 0D Sofware Version
OKdddd
dddd: FW version
~XX123 1
7E 30 30 31 32 33 20 31 0D Display Mode
OKn
n : 0/1/2/3/4/7/9/12
None/Presentation/Bright/Movie/sRGB/Blackboard/DICOM SIM./3D
~XX124 1
7E 30 30 31 32 34 20 31 0D Power State
OKn
n : 0/1 = Off/On
~XX125 1
7E 30 30 31 32 35 20 31 0D Brightness
OKn
~XX126 1
7E 30 30 31 32 36 20 31 0D Contrast
OKn
~XX127 1
7E 30 30 31 32 37 20 31 0D Format OKn n: 1/2/3/5/6/7 =4:3/16:9/16:10/LBX/Native/Auto
*16:9 or 16:10 depend on Screen Type setting
~XX128 1
7E 30 30 31 32 38 20 31 0D Color Temperature
OKn
n :3/0/1/2 = Warm/Standard/Cool/Cold
~XX129 1
7E 30 30 31 32 39 20 31 0D Projection Mode
OKn
n : 0/1/2/3 = Front-Desktop/ Rear-Desktop/ Front-Ceiling/ Rear-Ceiling
~XX150 1
7E 30 30 31 35 30 20 31 0D Information
OKabbbbccdddde
a : 0/1 = Off/On
bbbb: LampHour
cc: source 00/01/02/03/04/05/07/10/15 =
None/DVI/VGA1/VGA2/S-Video/Video/BNC/HDMI/Component/DisplayPort
dddd: FW version
e : Display mode 0/1/2/3/4/7/9/10=
None/Presentation/Bright/Movie/sRGB/Blackboard/3D/DICOM.
~XX151 1
7E 30 30 31 35 31 20 31 0D Model name
OKn
n:1/2/3=X605/W505/EH505
~XX108 1
7E 30 30 31 30 38 20 31 0D Lamp Hours
OKbbbb
bbbb: LampHour
~XX108 2
7E 30 30 31 30 38 20 31 0D Cumulative Lamp Hours OKbbbbb bbbbb: (5 digits) Total Lamp Hours
~XX87 1 7E 30 30 38 37 20 31 0D Network Status Okn n=0/1
Disconnected/Connected
~XX87 3 7E 30 30 38 37 20 33 0D IP Address Okaaa_bbb_ccc_ddd
