5.4 Advanced BIOS Features
Phoenix – AwardBIOS CMOS Setup Utility
Advanced BIOS Features
► CPU Feature
[Press Enter]
Item Help
► Hard Disk Boot Priority
[Press Enter]
CPU L3 Cache
[Enabled]
Hyper-Threading Technology
[Enabled]
Quick Power On Self Test
[Enabled]
First Boot Device
[USB-FDD]
Second Boot Device
[USB-CDROM]
Third Boot Device
[Hard Disk]
Boot Other Device
[Enabled]
Boot Up NumLock Status
[On]
Gate A20 Option
[Fast]
Typematic Rate Setting
[Disabled]
x Typematic Rate (Chars/Sec)
6
x Typematic Delay (Msec)
250
Security Option
[Setup]
x APIC Mode
Enabled
MPS Version Control For OS
[1.4]
OS Select For DRAM > 64MB
[Non-OS2]
Report No FDD For WIN 95
[No]
Full Screen LOGO Show
[Disabled]
↑↓→←:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
ü CPU Feature
Untermenü: siehe "CPU Feature" (p. 45)
ü Hard Disk Boot Priority
Untermenü: siehe "Hard Disk Boot Priority" (p. 46)
ü CPU L3 Cache
Optionen: Enabled / Disabled
ü Hyper-Threading Technology
Optionen: Enabled / Disabled
ü Quick Power On Self Test
Optionen: Enabled / Disabled
ü First Boot Device
Optionen: LS120 / Hard Disk / CDROM / ZIP100 / USB-FDD / USB-ZIP / Legacy LAN / Onboard
LAN 00C8 / Disabled
ü Second Boot Device
Optionen: LS120 / Hard Disk / CDROM / ZIP100 / USB-FDD / USB-ZIP / Legacy LAN / Onboard
LAN 00C8 / Disabled
ü Third Boot Device
Optionen: LS120 / Hard Disk / CDROM / ZIP100 / USB-FDD / USB-ZIP / Legacy LAN / Onboard
LAN 00C8 / Disabled
ü Boot Other Device
Optionen: Enabled / Disabled
ü Boot Up NumLock Status
Optionen: Off / On
ü Gate A20 Option
Optionen: Normal / Fast
