Scope of delivery
G&D FIBREVision-USB 2.0 · 4
Scope of delivery
Standard scope of delivery of the series
 1 × Computer module (FIBREVision-CPU)
 1 × User module (FIBREVision-CON)
 2 × Power cable (PowerCable-2 Standard)
 1 × Video cable (DVI-D-SL-M/M-2)
 1 × PS/2 twin cable (Twin-PS/2-M/M-2)
 2 × USB device cable (USB-AM/BM-2)
 1 × Service cable (Update-Cable-2)
 1 × Installation guide
 1 × Operating guide
Additional scope of delivery for expanded variants
The scope of delivery for expanded variants of the FIBREVision series additionally
includes the cables that are listed below.
Variants with audio and RS232 transmission
 2 × Audio cable (Audio-M/M-2)
 1 × serial connection cable (RS232-M/F-2)
Additional scope of delivery for multi-channel variants
Multi-channel variants of the series include a separate video cable for each video chan-
nel. FIBREVision-MC2 variants, for example, are shipped with two video cables.
NOTE: The scope of delivery of multi-channel devices provides several rackmount sets
(19” RM-Set-435) in order to install the devices to a 19” rack. The devices can
either be installed with the front panel or the back panel facing forwards.
Single-channel devices are available as desktop or as rackmount variant. Rackmount
variants must be installed to the rack with the front panel facing forwards.
