Supported graphic resolutions

7 · G&D DVISplitter2-DL

Supported graphic resolutions

The DVISplitter2-DL supports all resolutions that can be transmitted according to

DVI specification. This restriction mainly affects the pixel rate, which can reach

from 25 MHz (single link) to 165 MHz (dual link) or from 165 to 330 MHz.

During single link operation, the common VESA DMT and VESA SMT timing

standards enable resolutions between 640 × 480 pixels at 60 Hz and 1600 × 1200 pix-

els at 60 Hz.

1920 × 1200 pixels at 60 Hz are transmitted according to VESA CVT-RB, 1920 × 1080

pixels at 60 Hz (progressive) are transmitted according to CEA861.

Among other resolutions, dual link operation additionally supports the resolutions

2560 × 1600, 2048 × 2048 and 1920 × 2160 pixels (each at 60 Hz) according to

VESA CVT-RB.

Within the given parameters, you can adjust almost any refresh rate and resolution.

The available display modes depend on the graphics card, the graphics driver, the

operating system and the connected monitor.

The video data that is transmitted from the video source to the DVISplitter2-DL is not

altered when it reaches the monitor.

NOTE:

While generating the video signal, many graphics cards differentiate

between digital and analog output. Such graphics cards create digital image sig-

nals for the DVISplitter2-DL.
Independently of the operating system, some graphics cards therefore scale the

image to the resolution selected at the DDC switch on the DVISplitter2-DL. If nec-

essary, use the DDC switch to select the desired (native) resolution (see page 5).
