JB-Lighting Varycolor P3 250 HTI - Handbuch (Seite 25)

3.2 Set to factory default
3.4 Standalone mode
3.3 DMX Addressing
Enter DMX address by means of the keys "+" and "-". Confirm an store by pressing
key "Enter".
To set back the VC P3 to factory setting press key "Menu" one time.
will be displayed. Press key "Enter" to enter
menu. Select and press key "Enter". will be
displayed. Confirm by pressing key "Enter" again. The personal setting of the
VS P3 will be set back to factory default.
FACTORY DEFAULT FACTURY
DEFAULT LOAD DEFAULTS SURE
A sequence consisting of preprogrammed cues can be recalled by means of the
Standalone mode. The sequence will run as a loop. Cues can be entered in two
different ways.
The first way is to program every feature by means of the key of the units own
control panel. The second way is to program the cues by means of a connected
DMX control console and to store them on-board of the VS P3.
Add one step to the sequence:
Press key "+" untill menu
is shown. Confirm by pressing key "Enter".
will be displayed. Confirm by pressing key "Enter" again.
A new step will be added to the sequence.
The DMX values of the last step will be automatically copied to the new step.
To older DMX values enter Modify menu and proceed like describe in chapter:
Enter DMX values by means of the control panels keys.
INSERT
SURE?
Enter DMX values by means of the control panels keys:
The Modify menu enables access to all parameters of the unit. Use key "+" and "-"
to recall the desired parameter. Confirm choice by pressing "Enter". Enter DMX
values by means of the keys "+" and "-". Store DMX values by pressing key "Enter".
To escape press key "Menu".
Recall standalone mode:
Press key "Menu", then press key "+" five times (s. page 24)
will be displayed. Confirm by pressing "Enter",
will be shown. Confirm
again with "Enter". After this the display will show: . Now recall Modify
Menue by pressing "Enter".
STANDALONE STEPS
STEP NR. 1/1
MODIFY 1/1
Delete one step of a sequence:
Recall the Standalone menue.
must be shown on the display.
Confirm by pressing key "Enter". will be displayed. Use keys "+" and "-"
to recall the desired steps. Confirm selection by pressing "Enter". Select menue
with "+". Confirm the selection of the step by pressing "Enter". will
be displayed. Now confirm again by pressing "Enter". The selected step will be deleted.
STANDALONE STEPS
STEP NR: 1/X
DELETE SURE?
JB-lighting Lichtanlagentechnik GmbH Sallersteigweg 15 D-89134 Blaustein Telefon +49 (0)7304-9617-0
25
