Revox ICS 52 - Handbuch (Seite 27)

IWS + ICS Re:sound I
11
Adjusting speaker colour
Painting the speaker grill
You should remove the internal
fleece first, if the grill also is to be
painted. The fleece has an adhesive
surface, which allows you to put the
fleece back in position once the paint
has dried.
If the fleece does not adhere any
more, you can use a standard spray
adhesive.
Disassembling
Take off the speaker grill from the
frame with help of a flat object such
as a knife or similar. The frame with
the speaker grill can easily be
removed due to the magnetic fixture.
Hold the speaker in position and
unscrew the four fixing screws until
the head of the screw protrudes by
about 1 mm. The four rotary
tensioners are now back in the install
position and the speaker can be
removed.
Technical hints
Cable lengths
In order to keep the line and treble
loss as low as possible, we
recommend that you use the
following cable profiles and in any
case, you should use 2-core wire.
Up to 15 m:
Ø 0.75 mm
2
Up to 30 m: Ø 1.50 mm
2
Over 30 m: Ø 2.50 mm
2
Up to 50 ft:
AWG 17
Up to 100 ft: AWG 14
Over 100 ft: AWG 12
We advise that you avoid using cable
lengths above 50 metres, in order to
avoid loss of hi-fi reproduction.
Load capacity
It is possible to operate these
speakers with amplifiers that have a
higher output performance. In this
case however, you must ensure that
the volume is only turned up to a
level where your ear (usually a
reliable measure) starts to notice an
overload.
Your Revox speakers will not be
damaged by a short-term overload.
