12 GB/IE
Note: The integrated engine brake ensures that
the device comes to a rapid standstill.
Q Setting the direction of rotation
j With the rotational direction switch 6 you can
change the rotational direction of the electrical
tool.
NOTE: This is, however, not possible when the
ON / OFF switch
4 is pressed down.
NOTE: Hold the appliance in the direction of work.
Clockwise rotation:
j Push the rotational direction switch 6 to the
right in order to drill and to screw in screws.
Anticlockwise rotation:
j Push the direction of rotation switch 6 to the
left to slacken a screw or screw it out.
Q Switching between drilling /
hammer - action
Note: The hammer - action drilling mode is intend-
ed for drilling into brick, concrete and stone only.
Note: The drill / hammer - action switch
2 must
only be moved after the device has come to a
standstill.
Drilling:
j Set the drill / hammer - action switch 2 to the
right into the position.
Impact drilling:
j Set the drill / hammer - action switch 2 to the
left into the position.
Q Servicing and cleaning
DANGER OF INJURY!
Switch the device off and pull the plug out of the
mains socket before carrying out any work on the
device.
Apart from the jobs described above, the appliance
is maintenance free.
j Do not allow any liquids to enter the device.
Use a cloth to clean the device.
j Clean the device after you have finished using it.
j Do not under any circumstances use petrol or
strong solvents.
j Clean the dust extraction device 11 by dismant-
ling it as described above and knocking it.
j Store the device in a dry room.
Q Service centre
Have your device repaired
only by qualified specialist personnel
using original manufacturer parts only.
This will ensure that your device remains safe
to use.
If the plug or mains lead
needs to be replaced, always have
the replacement carried out by the
manufacturer or his service centre. This
will ensure that your device remains safe to use.
Q Warranty
The warranty for this appliance is for 3
years from the date of purchase. The ap-
pliance has been manufactured with care
and meticulously examined before deliv-
ery. Please retain your receipt as proof
of purchase. In the event of a warranty
claim, please make contact by telephone
with our Service Department. Only in this
way can a post - free despatch for your
goods be assured.
The warranty covers only claims for material and
maufacturing defects, but not for transport damage,
for wearing parts or for damage to fragile compo-
nents, e.g. buttons or batteries. This product is for
private use only and is not intended for commercial
use.
First use / Servicing and cleaning / Service centre / Warranty
